V Cut Acoustic Wall Panels

ACOUSTIC SURFACES

Öra V

V Cut Acoustic Wall Panels

Quiet Mark

A unique range of V cut patterns designed and produced by our in-house team. With a wide range of colours and designs, there’s no limit to how creative you can get with acoustics. From our graphic zigzag design to a variety of linear shapes and curvilinear patterns, Öra V can be used either as a single sheet or as a repeating pattern over several panels to create a large-scale statement wall. If you have a particular design in mind that is not part of our portfolio, or you want to create something that reflects your client’s culture and branding, we can quickly create a prototype using our in-house CNC machine.

V Cut Acoustic Wall Panels

Öra V

Combining creativity with acoustic performance is what our products are all about and with Öra V acoustic wall panels you can create visually striking walls whilst reducing reverberation. You can introduce biophilic design elements with our Barley, Flourish and Autumn designs, or get edgy and geometric with our more angular designs – the choice is yours. You can also take your creativity a step further with our dual colour option, combining a vibrant coloured base felt with a Camira Sonus fabric to create something truly bespoke. We can quickly create a prototype, provide you with a sample and advise on the best way forward, giving you the confidence that what you design is what we deliver.


Features

  • Available in 12mm and 24m thickness
  • 1200mm x 2400mm per panel
  • Made from 60% recycled PET (from used plastic bottles)
  • Easy to install with contact adhesive
  • 100% Recyclable at end of life
  • Designed and manufactured in the UK
  • Manufacturer’s 5-year guarantee
  • Not affected by moisture, mould or mildew
  • No formaldehyde binders
  • Low VOCs
  • Noise Reducing Coefficient (NRC) .45
  • Different mounting options available to increase NRC rating
  • Large range of designs to chose from to create your own bespoke design
  • REACH: PASS
  • Fire Rating EN 13501-1:2007+a1:2009 – B, s1, d0 ASTM E84-16 – Class A
  • BIM files available to download below

Autumn

V Cut Acoustic Wall Panels

Barley

V Cut Acoustic Wall Panels

Flourish

V Cut Acoustic Wall Panels

ZigZag

V Cut Acoustic Wall Panels

Chained

V Cut Acoustic Wall Panels

Jigsaw

V Cut Acoustic Wall Panels

Checked

V Cut Acoustic Wall Panels

Quadratic

V Cut Acoustic Wall Panels

Truss

V Cut Acoustic Wall Panels

Links

V Cut Acoustic Wall Panels

Orient

V Cut Acoustic Wall Panels

Colours

Allsfar Colours Rosella Red
Allsfar Colours Rosella Red Fleck
Allsfar Colours Oriole Orange
Allsfar Colours Oriole Orange Fleck
Allsfar Colours Flamingo Pink
Allsfar Colours Canary Yellow
Allsfar Colours Canary yellow Fleck
Allsfar Colours Lark Mustard Fleck
Allsfar Colours Goldcrest Green Fleck
Allsfar Colours Woodpecker Green
Allsfar Colours Woodpecker Green Fleck
Allsfar Colours Peacock Teal Fleck
Allsfar Colours Mallard Teal
Allsfar Colours Swallow Dark Blue
Allsfar Colours Jacarina Blue Fleck
Allsfar Colours Kingfisher Blue Fleck
Allsfar Colours Sabrewing Purple Fleck
Allsfar Colours Owl Dark Beige Fleck
Allsfar Colours Wheatear Beige
Allsfar Colours Wheatear Beige Fleck
Allsfar Colours Sanderling Grey
Allsfar Colours Dollarbird Blue Grey Fleck
Allsfar Colours Heron Grey
Allsfar Colours Skua Grey
Allsfar Colours Raven Black
Allsfar Colours Dove White

Downloads

BIM

CAD

Spec Sheet

Images

Technical Specifications

Composition 100% Polyester Fibre (PET)
Dimensions 2400 x 1200mm (+/- 5mm)
Thickness 12mm / 24mm
Weight 2.2kg/m2
Density 185kg/m3
Fire Rating EN 13501-1:2007+A1:2009 - B - s1, d0 ASTM E84-16 - Class A

Acoustic Performance

Ora 12mm

Ora 24mm

V Cut Acoustic Wall Panels
V Cut Acoustic Wall Panels
V Cut Acoustic Wall Panels
V Cut Acoustic Wall Panels
