Acoustic ceiling rafts
Our acoustic ceiling rafts can be used across a wide range of spaces to absorb sound and reduce echo. They’re easy to install and can be cut to any shape including circles, ellipses, squares, clouds, leaves and many more allowing you to create striking ceiling designs.
Downloads
BIM
CAD
Spec Sheet
Install Guide
Features
- 24mm PET felt
- Made from 60% recycled PET
- Available in 40+ nature inspired colours
- No formaldehyde binders
- Low VOCs
- Created in-house delivering fast lead times and complete creative control
- Bespoke panels can be created from your designs
- Exciting range of designs provides visual interest to ceilings
- Not affected by moisture, mould or mildew
- Easily retro-fitted to ceilings
- EN 13501-1:2018-B, s1, d0; ASTM E84 -16 - Class A
- BIM files available to download
- Aluminium channels available in black and white
Technical Info
Squares dimensions (mm) / Order qty multiple
- 600 x 600 x 24 / 8
- 800 x 800 x 24 / 3
- 1000 x 1000 x 24 / 2
- 1200 x 1200 x 24 / 2
Rectangles dimensions (mm) / Order qty multiple
- 600 W x 1200 L x 24 / 4
- 800 W x 1200 L x 24 / 3
- 1200 W x 2400 L x 24 / 1
Circles dimensions (mm) / Order qty multiple
- 600 diameter x 24 / 8
- 800 diameter x 24 / 3
- 1000 diameter x 24 / 2
- 1200 diameter x 24 / 2
- 2400 dia x 24 (two parts) / 1
Triangle (Equilateral) dimensions (mm) / Order qty multiple
- 800x800x800 x 24 / 6
- 1200x1200x1200 x 24 / 3
Triangle (Right angle triangle) dimensions (mm) / Order qty multiple
- 600 x 600 x 24 / 8
- 800 x 800 x 24 / 6
- 1200 x 1200 x 24 / 3
Hexagon dimensions (mm) / Order qty multiple
- 693ete x 800ptp x 24 / 4
- 779ete x 900ptp x 24 / 3
- 1095ete x 1264ptp x 24 / 2
*ete – edge to edge / ptp – point to point
Acoustic Performance
- 24mm directly on surface: 0.65 NRC / Class D
- 24mm with 100mm void: 0.90 NRC / Class A
- 24mm with 200mm void: 1.00 NRC / Class A
Fixings
Fixed suspension kit
Adjustable suspension kit
Colours
Sample Request
Designs
Squares
Rectangles
Circles
Triangle (Equilateral)
Triangle (Right Angle)
Hexagon
Donut
Cog
Cloud
Ivy
Leaf
Bespoke designs available on request
Aurora Projects
Ross Video – 3-Space (UK) Ltd
To help with zoning the different areas and managing the reverberation within the open plan area, 3-Space installed a range of Lull suspended acoustic screens in bespoke sizes as well as a range of bespoke-sized coloured ceiling rafts and baffles.
