Features
- Available in 12mm and 24mm thickness
- 2400mm x 1200mm per panel
- Made from 60% recycled PET
- Noise Reducing Co-efficient (NRC) 0.45
- Different mounting options available to increase NRC rating
- Large range of designs to choose from or create your own bespoke design
- Dual colour option available using Camira Sonus fabric
- Manufacturer’s 5 year guarantee
- Not affected by moisture, mould or mildew
- No formaldehyde binders
- Low VOCs
- Easy to install with contact adhesive
- EN 13501-1:2018-B, s1, d0; ASTM E84 -16 - Class A
- BIM/Revit files available to download
Technical Info
Specifications
- Composition: 100% Polyester Fibre (PET)
- Dimensions: 2400 x 1200mm (+/- 5mm)
- Thickness: 12mm / 24mm
- Weight: 2.4kg/m2
- Density: 185kg/m3
- Fire Rating: EN 13501-1:2018-B, s1, d0; ASTM E84 -16 - Class A
Acoustic Performance
- 12mm directly on surface: 0.4 NRC / Class E
- 12mm with 25mm void: 0.6 NRC / Class D
- 12mm with 50mm of acoustic wadding: 0.95 NRC / Class A
- 24mm directly on surface: 0.65 NRC / Class D
- 24mm with 100mm void: 0.9 NRC / Class A
- 24mm with 200mm of acoustic wadding: 1.0 NRC / Class A
Colours
Camira Sonus and Gabriel Hush and other non-woven fabrics are also available.
Sample Request
Fabrics
Fabric for our Öra V Dual surfaces come courtesy of global leader in contract, Camira.
